Design Specifications. One 8 cm circular entrance (yellow)Three 10cm x 10cm available paths (red)Two 4cm x 3 cm exits (blue)One 4cm x 4 cm exit (blue)Volumetric flow rate of 5.0 m3/sAir @ 25 degrees C. Design Goals . Minimize pressure lossesEqualize flow rates through the three ducts or pathsMinimize cost.
