  1. Capriccio: Scalable Threads For Internet Services Authors: Rob von Behren, Jeremy Condit, Feng Zhou, George C. Necula, Eric Brewer Presentation by: Will Hrudey

  2. Introduction • Capriccio: “a spritely improvisational musical dance involving multiple voices” • Introduces a fast, scalable user-level thread package for thread management and synchronization

  3. Motivation • Internet Servers And Databases • Have ever-increasing scalability needs • Need to handle hundreds of thousands of simultaneous connections without significant degradation • Need for a programming model to achieve efficient, robust servers with ease

  4. Approach • Utilizes user level threads to provide a natural abstraction for high concurrency programming • Prior work discussed threads versus events • Decouples thread package from OS to take advantage of: • Cooperative threading • New asynchronous I/O interfaces • Compiler support • Provides 3 key features: • Scalability • Linked stacks • Resource aware scheduling

  5. Goals • To allow high performance without high complexity • Support for existing thread API’s (POSIX) • Scalability to 100,000’s threads • Flexibility to address application-specific needs • Little or no modification of application itself

  6. User Level Threads • Provide performance & flexibility advantages • Provide a clean programming model with useful invariants and semantics • Decouples thread package from OS • Hides both OS variation & kernel evolution • Integrate compiler support • Can complicate preemption • Can interact badly with kernel scheduler

  7. User Level Threads • Flexibility • Take advantage of new asynchronous I/O mechanisms • Tailored scheduling • Lightweight (scale to 100,000 threads) • Performance • Reduced synchronization overhead on uniprocessors • More efficient memory management • Disadvantages • Blocking I/O • Wrapper layer to translate blocking to non-blocking I/O • Lightweight synchronization diminished on multiprocessors

  8. User Level Threads • Implementation (user level library for Linux) • Context switches • coroutine library • I/O: intercepts blocking I/O calls • epoll() for pollable file descriptors and Linux AIO • Scheduling: • Main loop looks like an event-driven application • Run threads and checks for I/O completions • Synchronization • Cooperative scheduling to improve synchronization • Efficiency • Thread management functions have bounded worst case running times

  9. User Level Threads • Microbenchmark: • Testbed: • 2x2.4GHz Xeon / 1GB / 2x10K RPM SCSI Ultra II HD / 3xGigabit Ethernet / Linux 2.5.70 • Thread packages: • Capriccio, LinuxThreads, NPTL

  10. Efficient Stack Management • Optimizes stack allocation for many threads • Reduces size of VM dedicated to stacks • Small non-contiguous stack chunks • Grow and shrink at run time • Compiler analysis and runtime checks • Generates a weight directed call graph

  11. Efficient Stack Management • Nodes are functions weighted by max stack size • Edges indicate function calls between nodes • Path is a sequence of stack frames • Checkpoints are code inserted at call sites Weighted Call graph

  12. Efficient Stack Management • Places a reasonable bound on the amount stack space consumed by each thread • Checkpoints determine if enough space left to reach next checkpoint without overflow • If not, new stack chunk allocated & SP adjusted • Checkpoint placement • Break cycles • Scan nodes to ensure path within desired bound

  13. Efficient Stack Management • Special cases • Function pointers complicate analysis • External function calls • Tuning to optimize memory usage • MaxPath • MinChunk • Linked stacks can improve paging behavior • Apache SPECweb99 results: 3-4% slowdown overall

  14. Resource Aware Scheduling • Thread scheduling and admission control adapt to resource usage • Application viewed as sequence of stages separated by blocking points • Dynamic scheduling decisions are finer grained • Blocking graphs generated at runtime • Learn behavior dynamically to improve scheduling • Determine impact on resource utilization if schedule thread

  15. Resource Aware Scheduling Blocking Graph • Nodes are program locations where threads block • Edges reflect consecutive blocking points • Edges annotated with weighted averages reflecting resource usage • Nodes annotated with weighted outer edge values • Threads walk this graph independently

  16. Resource Aware Scheduling • Promote nodes that release resources and demote nodes that acquire resources • Dynamically prioritize nodes (threads) for scheduling • Responds to changes in resource consumption due to type of work and offered load • Implement using separate run queues for each node

  17. Resource Aware Scheduling • Usage • Drive each resource to max capacity, throttle back, coupled with hysteresis, keeps system at full throttle • Challenges • Determination of max capacity of resources is tricky • Interaction between resources • Thrashing can be difficult to detect • Application specific resources – memory mgmt

  18. Performance • Evaluate real-world web server workload Testbed • 4x500 MHz Pentium / 2GB / Gigabit Ethernet • Linux 2.4.20 • Kernel version doesn’t support epoll or AIO (used poll) • Client load up to 16 similar configurations • 3.2GB static file data with various file sizes • Clients repeatedly connect, issue 5 requests waiting 20ms apart • Limited cache sizes: Haboob / Knot to 200MB to force disk activity • Request frequencies for each size and file based on SPECweb99

  19. Performance • 15% increase with Apache • Knot comparable to event-based Haboob

  20. Performance • Overhead involved in maintaining information about resources at each node • Gathering and maintaining statistics: • <2% for edges in Apache • Statistics remained fairly steady in tested workloads • Ratio of 1/20 reduces aggregate overhead to 0.1% • Stack trace overhead significant • (8% - Apache / 36% - Knot) • Could be reduced with compiler integration

  21. Future Work • Incorporate multiprocessor support • Reduce kernel crossings under heavy load with a batching interface for async I/O • Improve thrashing detection • Improve stack analysis – function pointers (CCured) • Develop profiler tools to optimize tuning parameters • Generate blocking graph at compile time • Implement blocking point fairness strategies

  22. Conclusion • Thread package was “fixed” to support scalable, high concurrency Internet servers • Threading model is more useful for high concurrency programming • User level thread package is decoupled from OS • Can benefit from new I/O mechanisms and compiler support • Linked stacks and scheduler delivered significant improvements in scalability and performance compared with existing systems

  23. Observations • External function call stack size doesn’t scale • Offloads responsibility to compiler support “compiler technology will play an important role in the evolution of the techniques described in this paper” • Performance test • Data not qualified: how many runs? Are results repeatable? • Kernel didn’t have same non-blocking call support so comparison is difficult; are the results still meaningful? • Stated goal of achieving 100,000’s of threats not explicitly evident

  24. Discussion • It seems as though using a graph to dynamically adjust the stack size (vs a default large stack size) is a smart thing to do, especially if memory is a problem. I'm trying to figure out if this is a new era of more intelligent thread packages, or if this is an overly complex solution which has been avoided. So what is the expense (in terms of computation) of this intelligent stack management? Is it necessary for this application to succeed?

  25. Discussion • Capriccio can scale to 100,000 threads, what about more than 100,000 thread? Will the system just crash? Is there no mechanism in place if that happens? • I was wondering whether the dynamic stack chunks are mapped contiguously in the virtual memory of the thread? If this was the case, how could they achieve adding a chunk of memory to the stack as small as half a page?

  26. Discussion • In the experimental section there is no mention of how many tests were performed, and from the looks of it, there was just one---since otherwise vanilla-apache seems to dip and then improve in bandwidth as more clients connect. Also Knot seems to have approximately the same performance as Haboob, so I'm wondering how conclusive these tests really are?

  27. Discussion • The authors continually refer to their program’s ‘event-driven behavior’ (page 3,8, 11). In this way, it is a similar implementation to SEDA (in that both event and thread behaviors are exhibited). What is the implied advantage of fixing threads to behave like events over fixing events to behave like (or use) threads?

  28. Discussion • What the authors seem to be doing with the scheduling of the system is wrap an event-based behavior (for I/O) into a thread-based abstraction. Is this extra layer of abstraction really needed? How much does the extra layer of abstraction affect the performance of the system in general? Also, why is it that people don't accept the fact that events are better for this type of task and just use them as they are, as opposed to dressing them up in thread costumes?

  29. Discussion • One assumption that the authors make is that resource usage is likely to be similar for many tasks at a blocking point. They say that this assumption *seems* to hold in practice. This is of course not too convincing. Is this actually a good assumption to make? Are there any systems where this does not hold, and what would be the consequences on this piece of work?

  30. Discussion • Authors commented that the resource-aware scheduling is completely adaptive, but also confess that the system suffers from several parameter tuning problem like knowing maximum capacity of each resource, adjusting speed of adaptation (no reason why they use exponentially weighted averages). Finding optimal parameters can be another huge work to do which could be too hard to be tuned by hand. Isn't it making things more complicated or uncontrollable?

  31. Discussion • One of the key features that is incorporated into Capriccio is a new method of stack management, linked stack management, whose goal is to improve performance by reducing the amount of wasted stack space, typical with other types of stack management. Their approach is contingent on compiler support. Is it realistic to expect to see the development of a compiler for this purpose?

  32. Discussion • In the case study, the authors choose MaxPath and MinChunk, the two tuning parameters available with their linked stack management algorithm, based on profiling information. Is it reasonable to expect the programmer to supply this information? How sensitive is the algorithm to these parameters?

  33. Discussion • Would it be possible to use something like NPTL under low-load, since it performs better than Capriccio, then switch to Capriccio under higher loads when it begins to outperform NPTL? This would give the best of both and constantly maintain good performance.

  34. Discussion • In Section 3.1, the authors used whole-program analysis to determine the maximum amount of stack space that a single stack frame for that a function will consume. How about dynamic memory allocation? If the codes allocate various size of memory during run-time, how could the program estimate the maximum stack size (or they just give a rough estimation?)?
