Ble 4.0 LED I/O

智慧調劑台調劑感 測系統開發 調劑台藥劑箱亮燈 機構取藥指引 系統. Ble 4.0 LED I/O. 調劑台上 的 抽屜 型 藥格. 後端由資訊部提供平台 ( 同現況自動藥包機模式，讀取資料 ) ，並由藥師可依據藥品異動，更新料位號後，亮燈系統同步更新。 需考慮日後維修與備料方便，亮燈模組的位址可用跳線設定。. 調劑台上的藥格安裝亮燈模組 A: 一大格 B:1/2 格 C:1/4 格. 桌面固定式 Barcode Reader 讀取藥袋上的 Barcode ，亮燈顯示顯示藥品位置 ( 抽屜、藥格亮燈 ) ，調配完讀取下一個藥袋時，原燈熄滅，亮新位址燈。.

asasia
Download Presentation

Ble 4.0 LED I/O

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 智慧調劑台調劑感測系統開發 調劑台藥劑箱亮燈機構取藥指引系統 Ble 4.0 LED I/O

  2. 調劑台上的抽屜型藥格 • 後端由資訊部提供平台(同現況自動藥包機模式，讀取資料)，並由藥師可依據藥品異動，更新料位號後，亮燈系統同步更新。 需考慮日後維修與備料方便，亮燈模組的位址可用跳線設定。

  3. 調劑台上的藥格安裝亮燈模組A:一大格 B:1/2格 C:1/4格 桌面固定式Barcode Reader讀取藥袋上的Barcode，亮燈顯示顯示藥品位置(抽屜、藥格亮燈)，調配完讀取下一個藥袋時，原燈熄滅，亮新位址燈。

  4. 智慧藥劑箱無線感測系統 LED04 LED03 LED02 LED01 LED08 LED07 LED06 LED05 LED12 LED11 LED10 LED09 LED16 LED15 LED14 LED13 -------------------------------------------------------------

  5. 智慧藥劑箱無線感測系統Ble.4.0 LED I/O 陣列式方格座標 U12 BI-Color LED P2.2—LED RED Tag ID P2.1—LED GRN Tag 電源 LED37 , LED38 LED39 , LED40 LED41 , LED42 LED43 , LED44 P00.P16 P01.P16 P02.P16 P03.P16 P04.P16 P05.P16 P06.P16 P07.P16 LED32 LED33 LED34 LED35 LED36 P00.P15 P01.P15 P03.P15 P05.P15 P07.P15 LED27 LED28 LED29 LED30 LED31 P00.P14 P01.P14 P03.P14 P05.P14 P07.P14 LED19 , LED20 LED21 , LED22 LED23 , LED24 LED25 , LED26 P00.P13 P01.P13 P02.P13 P03.P13 P04.P13 P05.P13 P06.P13 P07.P13 LED14 LED15 LED16 LED17 LED18 P00.P12 P01.P12 P03.P12 P05.P12 P07.P12 LED09 LED10 LED11 LED12 LED13 P00.P11 P01.P11 P03.P11 P05.P11 P07.P11 LED01 , LED02 LED03 , LED04 LED05 , LED06 LED07 , LED08 P00.P10 P01.P10 P02.P10 P03.P10 P04.P10 P05.P10 P06.P10 P07.P10

  6. Ble 4.0 LED PCB 調劑台藥劑箱亮燈系統 U12 BI-Color LED P2.2—LED RED Tag ID P2.1—LED GRN Tag 電源 C B E

  7. LED CON.PCB Ble.4.0調劑台藥劑箱亮燈系統 LED LED LED LED

  8. USB Dongle Ble.4.0 無線感測系統

  9. Ble 4.0 CC2540 Program • Open collector • 1k Ω • 2.0pin • 1.27pin
