Presentation Transcript


  1. TATES CREEK HIGH SCHOOL1111 centre parkwaylexington, kentucky 40517coach willoughbyIEDDrill Press DEVELOPED BY: MTW February 2011

  2. Drill Press Parts Power switch

  3. Drill Press Parts Speed Control

  4. Drill Press Parts Drill Bit Chuck Table

  5. Drill Press Parts Chuck Key

  6. Drill Press Parts Depth Gauge

  7. Drill Press Parts Table

  8. Drill Press Parts

  9. Drill Press When drilling through the work piece use a “Backer Board” under the work. This will help prevent tear out on the back side.
