  1. CIS 725 Network Layer

  2. Network Layer • This layer provides communication between any two nodes • Uniform addressing scheme independent of the network technology Network layer Data Link layer

  3. Problems to be addressed • Routing • Congestion control

  4. Routing • Processing nodes • Switches/routers • Communication links

  5. Datagram routing • Each packet is routed independently • Unordered • Unreliable

  6. Virtual Circuit routing • Set up a path for each connection • All messages are sent over this path • Ordered • Reliable

  7. Routing Table • Routing table contains the next hop information • At each node i, for each destination j, what is the next hop

  8. Distance Vector Algorithms Bellman-Ford Algorithm • Distance table: • Routing table distance from i to j via k

  9. Routing table • Protocol at node i: On receiving routing table from k update column k of the distance table as follows For each destination j, if k reports its distance to j as d then update Dj,k = d + weight(i,k)

  10. Recompute the routing table as follows: For each destination k, update next hop to j, where Dj,k = min(Dx,k: for all x)

  11. Periodically or whenever the routing table changes, send routing table to all neighbors

  12. Bellman-Ford Algorithm b c a c d a b e b c d e 2 a c d e 2 a b d e 4 4 1 1 b 2 d 2 2 2 a 1 1 b c d e b 2 a c d e a 2 a b d e 4 a 4 c 4 2 c e c 1 b 1 d 2 e 2

  13. Bellman-Ford Algorithm b c a c d a b e b c d e 2 a c d e 2 a b d e 4 3 4 1 3 5 1 b 2 d 4 6 2 3 2 2 a 1 1 b c d e b 2 a c d e a 2 a b d e b 3 4 b 3 2 c e c 1 b 1 b 4 b 3 d 2 e 2

  14. Bellman-Ford Algorithm • Distance vector algorithm • Best path criteria • Latency • Jitter • bandwidth

  15. Counting to infinity a 1  101 100 c b 1 a a c c a a a b b b a a a a c c a a a a a a a b b 100 100 4 2 4 2 101 101 1 5 3 3 1 5 3 b b b b b b b b b 3 3 3 1 1 1 1 1 1

  16. < a,b,c,d,e,f> 5 1 1 c 1 d 1 e 1 f a b 4 3 2 1 5 20 dest next dist path

  17. 5 1 1 c 1 d 1 e 1 f a b 4 3 2 1 5 b  c  d  e dest next dist Next to last hop b d e c f b b b b b 5 3 4 1 2 a c e d b

  18. Link State Routing • Each node maintains the state of every link • State of the link may contain several types of information

  19. Learning local information • Exchange hello packets periodically • Measure the cost of adjacent links

  20. Distributed link state information • Link state packet: * source id * cost of incident edges * sequence numbers

  21. Building Link State Packets (a) A subnet. (b) The link state packets for this subnet.

  22. Distribution Algorithm • Controlled flooding - hop count - sequence numbers - age

  23. Receive LSP from nbr j - compare sequence numbers - update topology table - propagate LSP to all nbrs except j

  24. Hierarchical Routing • Divide area into regions • Maintain accurate information about nodes in the same region

  25. Hierarchical Routing Hierarchical routing.

  26. Source-routing • Message contains the entire path • Routing table lookup is avoided at each node

  27. Broadcasting/Multicasting • To send a message to all nodes: - make a separate message to each destination - route each message independently

  28. Multi-destination routing • Include all destination address in message • Each node decides which links to forward so that it reaches all destinations

  29. Multicast trees • Create a spanning tree • Prune the spanning tree: Steiner tree
