  1. Machine Learning in Intrusion Detection Systems (IDS)

  2. 2 papers: • Artificial Intelligence & Intrusion Detection: Current & Future Directions [AIID] • J. Frank • Applying Genetic Programming to Intrusion Detection [GP] • M. Crosbie, G. Spafford

  3. AIID • What is intrusion detection? • What are the issues in Intrusion Detection? • Data collection • Data reduction • Behavior Classification • Reporting • Response

  4. AIID • AI methods are used to help solve some issues • For data classification: • Classifier systems • Neural Network • Decision Tree • Feature Selection

  5. AIID • Data Reduction • Data Filtering • Feature Selection • Data Clustering

  6. AIID • Behavior Classification • Expert Systems • Anomaly Detection • Rule-Based Induction

  7. AIID • An experiment using Feature Selection • Info. about network connections using a Network Security Monitor

  8. AIID • 3 Search algorithms used: • Backward Sequential Search (BSS) • Beam Search (BS) • Random Generation Plus Sequential Selection (RS)

  9. AIID • Algorithm performance

  10. AIID • Error Rate Performance (All) [T, PD, DS] Best [I, W, T, PS, PD, DS]

  11. AIID • Error Rate Performance (SMTP) Best [W, T, PS, PD, DS]

  12. AIID • Error Rate Performance (Login) [T, PD, DS]RGSS Best [W, T, PS, PD]

  13. AIID • Error Rate Performance (Shell) Best [W, T, PS, DS] RS [W, PS, PD, DS]BS & BSS

  14. GP(Applying Genetic Programming to Intrusion Detection) • An IDS that exploits the learning power of Genetic Programming • Two types of security tools : • Pro-active • Reactive : IDS falls in this catergory

  15. GP • Components in an IDS • Anomaly • May indicate a possible intrusion • So how do we know for sure? Expert-system • Rule-set = model • Metrics • Comparing metrics & model • But … If a new intrusion scenario arises modifying the IDS is complicated

  16. GP • A finer-grained approach IDS gets split into multiple Autonomous Agents

  17. GP

  18. GP • Using GP for learning • Instead of a monolithic static “knowledge base” • The GP paradigm allows evolution of agents that could be placed in a system to monitor audit data • GP programs • are in a simple meta-language • Have primitives that access audit data fields and manipulate them

  19. GP • Internal agent architecture

  20. GP • Learning by feedback • What do the agents monitor? • Inter-packet timing metrics: Total # of socket connections, average time between socket connections, minimum time between socket connections, maximum time between socket connections, destination port, source port • Potential intrusions looked for: Port flooding, port-walking, probing, password cracking

  21. GP • Δ = | outcome – suspicion | • Penalty = Δ * ranking /100 • Fitness = (100 – Δ) - penalty

  22. GP • Multiple types: • Time (long int), port (int), boolean, suspicion (int) • Problems with multiple types • ADF solution to type safety • ADF: Automatically Defined Function • To monitor network timing: avg_interconn_time, min_interconn_time, max_interconn_time • For port monitoing: src_port, dest_port • For privileged port checking: is_priv_dest_port, is_priv_src_port

  23. GP • Experimental results:

  24. That’s it !!!

  25. Too old a research idea … did not find any current researches in the same field
