  1. EEE 302Electrical Networks II Dr. Keith E. Holbert Summer 2001 Lecture 14

  2. Solving Differential Equations • Laplace transform approach automatically includes initial conditions in the solution • Exercise: For zero initial conditions, solve Lecture 14

  3. Inverse Laplace Transform • Consider that F(s) is a ratio of polynomial expressions • The roots of the denominator, D(s) are called the poles • Poles really determine the response and stability of the system • The roots of the numerator, N(s), are called the zeros Lecture 14

  4. Inverse Laplace Transform • We will use partial fractions expansion with the method of residues to determine the inverse Laplace transform • Three possible cases (need proper rational, i.e., n>m) (1) simple poles (real and unequal) (2) simple complex roots (conjugate pair) (3) repeated roots of same value Lecture 14

  5. Simple Poles • Simple poles are placed in a partial fractions expansion • The constants, Ki, can be found from (use method of residues) • Finally, tabulated Laplace transform pairs are used to invert expression, but this is a nice form since the solution is Lecture 14

  6. Class Examples • Extension Exercise E13.9 • Extension Exercise E13.10 Lecture 14

  7. Complex Conjugate Poles • Complex poles result in a Laplace transform of the form • The K1 can be found using the same method as for simple poles WARNING: the "positive" pole of the form -+j MUST be the one that is used • The corresponding time domain function is Lecture 14

  8. Class Example • Extension Exercise E13.11 Lecture 14

  9. Repeated Poles • When F(s) has a pole of multiplicity r, then F(s) is written as • Where the time domain function is then • That is we get the usual exponential multiplied by t's Lecture 14

  10. Repeated Poles (cont’d.) • The K1j terms are evaluated from • This actually simplifies nicely until you reach s³ terms, that is for a double root (s+p1)² • Thus K12 is found just like for simple roots • Note this reverse order of solving for the K values Lecture 14

  11. Class Examples • Extension Exercise E13.12 • Extension Exercise E13.13 Lecture 14
