  1. Higher walled map pocket Vertical door line Concept A.1

  2. Higher walled map pocket Door line follows existing forms Concept A.2

  3. Retain map pocket height Lengthen door Recess vertical wall Concept A.3

  4. Raise map pocket height Lengthen door Recess vertical wall Concept A.4

  5. Retain map pocket height Shorten horizontal line Concept B.1

  6. Concept B.2
