AirOxi Tube for Biofloc

Our aeration tubes are an ideal solution for a biofloc culture; our low maintenance solution helps to maintain better DO levels across the ecosystem with the help of bottom up diffusion. For more information check our presentation. Call: 91 - 7285017087

airoxitube
Download Presentation

AirOxi Tube for Biofloc

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Experts in Diffused Aeration Use of AirOxi Tube in Biofloc culture

  2. Key features of Bio Floc Technology (BFT) Key features of Bio Floc Technology (BFT) • Balancing Caron Nitrogen Cycle • Recycling nutrients in a natural way • Minimum water exchange • High Aeration needed to support bacteria and fish/shrimp

  3. Independent study on biofloc aeration Independent study on biofloc aeration A study on aeration methods for biofloc culture of L. Vannamei published in Aquaculture International February 2017 found diffused aeration to be the best aeration method for biofloc Stocking Density - 40 / sq mt 9 tanks of 35 sq mtr size (4900 pieces per tank) Initial weight – about 4.5 gram Study period – 33 days. Result after 33 days Aeration method Diffused aeration with Blower 4.91 Vertical Pump Propeller aerator DO – mg /L (Avg) 4.49 4.50 Final weight (Avg) 12.96 10.93 12.81

  4. AirOxi Tube Diffused Aeration System AirOxi Tube Diffused Aeration System • Blower based – low power consumption – 1/3rdof Paddle aerators • Bottom up diffusion – extremely efficient • Technology used worldwide in ETP / STP / WWTP and aquaculture • Uniform aeration throughout the pond – top and bottom • Entire ecosystem gets DO – better autotrophic cycle • Low Maintenance

  5. AirOxi AirOxi tube tube – – Ideal solution for Ideal solution for growout biofloc biofloc, nursery, RAS and Raceway , nursery, RAS and Raceway growout ponds, ponds, • Diffused aeration is the only option for nurseries, biofloc, RAS, Raceway and IPRS • AirOxi tube is used all over India in all these types of culture

  6. AirOxi Tube is also best solution for large AirOxi Tube is also best solution for large ponds. Airoxi v/s Paddle aerator in pond use ponds. Airoxi v/s Paddle aerator in pond use

  7. Eventual Benefits to Farmers Higher and more uniform DO, Faster DO leading to: • Higher Stocking Density – increase by 40-50% • Higher Immunity • Higher Survival – 85% to 95% • Faster Growth (saving of 10-20 days, even one additional crop/ year) • Low FCR • Reduced cost of power used for aeration – saving of 40-60%

  8. Comparative Efficiency of aeration methods kg/kwh lb/hp-h General Oxygen Transfer Efficiency (standard conditions) 11 10 9 8 7 6 5 4 3 2 1 6 High-Density / Low-Flux – Aeration Systems (fine bubble diffuser arranged in high density layout) 5 4 Typical Fine Bubble Diffuser System 3 Jet Aerators & Coarse Bubble Diffuser Systems 2 Mechanical Floating Aerators Aspirating FloatingAerators 1 Source - Environmental Dynamics International, Aeration efficiency guide 2011

  9. Measuring Aeration Energy Efficiency Amount of oxygen transferred Standard Aeration Efficiency (SAE) = Amount of energy added Depending on depth of installation and salinity of water, AirOxi tube diffused aeration system gives 2 to 3 times dissolved oxygen per HP of power used, compared to surface aerator

  10. Aeration Device Efficiency Increasing SAE Mechanical Aeration Coarse Bubble Aeration / Jet Aeration Fine Bubble Aeration 1 to 1.2 Kg O2 / HP-hr 1.5 to 2 Kg O2 / HP-hr 3 – 3.5 Kg O2 / HP-hr

  11. AirOxi Tube v/s paddle aerator – time taken to increase DO in 35 PPT salinity water AirOxi Paddle aerator

  12. AirOxi movies AirOxi movies

  13. Installation  1 time installation of Blower, AirOxi Tube and piping  Cost – 1.4 to 1.6 lac per hectare  Payback period – 1 to 2 cultures at most  3 to 5 year life  Very low maintenance cost over life of the system

  14. About the product and company About the product and company  Manufacturing base in Baroda, Gujarat - ISO 9001:2015 certified  50 years in specialized product manufacturing  10 years experience in manufacturing, testing and research of AirOxi Tube  RoHS certified product made from special Elastomeric Polymer compound (blend of domestic and imported raw material and additives)

  15. About the product and company About the product and company  AirOxi tube also exported to various countries including USA, Singapore, Germany, France and other countries in Europe, Africa, Asia and Middle East  Technical support, sales and distribution available almost all over India - Gujarat, Andhra Pradesh, Odisha, Karnataka, Kerala, Telangana, West Bengal, Bihar, Maharashtra.

  16. Innovation at AirOxi Innovation at AirOxi • Probably the largest range of aeration tubes by anyone in the world – 10 different sizes and shapes and variants • Widest range of diffusers from smooth tubes , nano bubble diffusers to high flow rate, with price range from 80 per mtr to 9000 per foot • Only company to manufacture high flow, large size tube 1”x 1.5” size for extra high aeration • Online aeration calculator available free of cost – The only such calculator in the world www.airoxi.com/calculator - this gives list of all materials and their approximate price

  17. Innovation Innovation – – a culture at AirOxi a culture at AirOxi • Animation videos of installation made specially so customers can install system easily • Design and offer a ready to use assembly – The AirOxi Spider • Offering Mobile Aeration System that works on tempo battery • Launch of ready aeration system packages for 1 tank and 5 tanks – Plug and Play

  18. Products Products

  19. Special solutions for biofloc culture Special solutions for biofloc culture – – AirOxi Spider AirOxi Spider

  20. Special solutions for biofloc culture Special solutions for biofloc culture – – Hi Flow tube tube – – large size 1”x 1.5” large size 1”x 1.5” – – WHITE LINE Hi Flow WHITE LINE

  21. Special solutions for biofloc culture Special solutions for biofloc culture – – Ready to use system packages for 1 tank of 10,000 ltr use system packages for 1 tank of 10,000 ltr Plug and Play Plug and Play Ready to 120 LPM AC air pump - 1 nos AirOxi spiders - 4 nos Tee, valves, Grommet, Take off, etc. as required 1/2" transparent PVC pipe - 20 mtr 10,000 ltr. Supports 500 Kg fish or 100 Kg Shrimp

  22. Special solutions for biofloc culture Special solutions for biofloc culture – – Ready to use system packages for 5 tank of 10,000 ltr use system packages for 5 tank of 10,000 ltr Plug and Play Plug and Play Ready to Blower 2 stage 1 HP single phase AirOxi spiders - 20 nos Discharge manifold with valves, Grommet, Take off, etc. 1/2" UV resistant flexible black PVC pipe - 100 mtr 50,000 ltr. Supports 4 ton fish or 1 ton shrimp

  23. Special solutions for Special solutions for biofloc use system packages for use system packages for 40 biofloc culture culture – – Ready to 40 mt mt x 40 x 40 mtr Ready to mtr pond pond Blower 2 stage 2 HP single phase AirOxi spiders - 40 nos Discharge manifold with valves, Grommet, Take off, etc. 1/2" UV resistant flexible black PVC pipe - 400 mtr 1.5 lac ltr. (150 ton) Supports 5 ton fish or 1.5 ton shrimp

  24. Special solutions for biofloc culture Special solutions for biofloc culture - - Mobile Aeration System that works on vehicle Mobile Aeration System that works on vehicle battery battery 120 LPM air pump - 1 nos AirOxi spiders - 4 nos Tee, valves, Grommet, Take off, etc 1/2" transparent PVC pipe - 15 mtr 3000 ltr. Supports 500 Kg fish or 100 Kg shrimp

  25. For more information and videos……… For more information and videos……… www.airoxitube.com www.Youtube.com/airoxitube www.facebook.com/airoxitube www.twiter.com/airoxitube info@airoxitube.com +91-72850-17087
