  1. Eastar (H.K.) Ltd.

  2. New Plant • The new plant is located in new industrial site of ChaShan • The total land area is over 30,000 m2 • Factory area is 21,000 m2, fully central air-conditioned • Dormitory area over 11,000 m2 • Dormitory provision for married staff • Environmental design • Constructional area < 40% • Green and leisure area > 60% • Dormitory designs make full use of sunlight for lighting • Full compliance to updated fire & environmental regulations in China, energy saving, all drink water purified, buffet style for workers

  3. Introduction • Headquarter in Hong Kong • Factory in DongGuan, China • Rep in USA, Canada, Europe • Fully integrated manufacturing Setup • life safety products • power supplies • PCB assemblies • wire-wound components • Associated companies • Sheet metals • Plastic parts

  4. History

  5. Product Development

  6. Organization Chart

  7. Current products • Transformers & inductors • Solenoids & other wire-wound components • SMT/PTH PCB assemblies • Electronic system assemblies • Power supplies & Power converters • Life & security products • Clocks (e.g. Synchronized Clocks)

  8. Capability • Transformers up to 6kVA (115kVA under development) • Planar transformers up to 3kVA • Power supplies up to 4kW • Power converters up to 1000W • SMT assemblies down to 0402 chips • Life & security products per IPC 610 Class 3 requirements • High temperature burn-in • HP3065/3070 testing with in-house programming & fixtures • Dedicated functional tester design & build • Dedicated semi-automatic production tools

  9. Capacity • Currently employing over 900 employees • Current factory space is over 30k m2 • Daily production • Over 50k units of wire-wound components • Over 1 million tacts for SMT PCBA & system • Capacity utilization is about 60%

  10. Mission To Achieve & Maintain Excellence in • All Products • 100 % Customer Satisfaction

  11. Safety & Certification • 1st UL recognized products approval in 1992 • UL insulation system, Class B, Class F & Class H approval since 1994 • ISO-9002 (1994 version) certification since 1997, updated to ISO-9001 (2000 version) • TUV product and factory certification

  12. Quality Performance • Quality system ISO 9001:2000 Certified • Quality requirement is IPC 610 Class 3 • Mil-Std-2000 training programs for Engineers, Inspectors & Operators (Standards for Soldered Electrical and Electronic Assemblies) • Quality Mission – “Do It Right at the FirstTime”

  13. Major Equipment • 5 Juki SMT Machines (KE750, KE2020M,KE2050M) • 2 Sony Cellular Mounters SI-EI100 • 12 HP 3065 & 2 HP 3070 test systems • Environmental chambers • Hot air reflow soldering system • Dual wave soldering system • Vacuum impregnation system • Conformal coating line • Over-spraying painting line • Benson ultrasonic welders • Burn-in rooms

  14. MajorCustomers

  15. Our Next Step

  16. Thank you !
