  1. MIKROMETER - KINEX. CZ Rozsah merania 0 – 25 mm 25 – 50 mm 50 – 75 mm 75 – 100 mm 100 – 125 mm 125 – 150 mm

  2. Meradlo pred úpravou Typ 25 – 50 mm

  3. Meradlo pred úpravou Meradlo pred úpravou Typ 25 – 50 mm

  4. Meradlo po úprave Typ 0 - 25 mm

  5. Meradlo po úprave Typ 0 - 25 mm

  6. Úprava pevného dotyku v rozsahu 0,5 – 0,8 mm, podľa požiadavky

  7. Úprava hrotu vretena v rozsahu 60° / 0,5 – 0,8 mm, podľa požiadavky
