  1. ActiveX Controls Presenters:Chris Gillespie Jerry Beaverson

  2. Pridgeon and Clay Introduction Presentation: Welcome to Pridgeon and Clay

  3. Part Portfolio - Global

  4. ActiveX Controls • ActiveX Controls – Definition • Allows you to control an application through another application (like a puppet on a string) • Allows you to “prep” data and then load it • P&C’s Migration to the Use of ActiveX controls • Began about nine years ago • Expanded use over time • Useful tool to chart and graph (without the expense of a report writer) • Examples of How ActiveX Controls Can be Used • Capacity planning • Steel surcharge calculations • Price data loading • Router changes

  5. ActiveX Controls

  6. ActiveX Controls

  7. ActiveX Controls Transition from Microsoft world Visual BasicProgress Range("A1:C13").Select ActiveWorkbook.Worksheets("Sheet2").PivotTables("PivotTable1").PivotCache. _ CreatePivotTable TableDestination:="", TableName:="PivotTable1", _ DefaultVersion:=xlPivotTableVersion10 With ActiveSheet.PivotTables("PivotTable1").PivotFields("Order Qty") .Orientation = xlRowField .Position = 1 End With With ActiveSheet.PivotTables("PivotTable1").PivotFields("Part No") .Orientation = xlRowField .Position = 2 End With ActiveSheet.PivotTables("PivotTable1").AddDataField ActiveSheet.PivotTables( _ "PivotTable1").PivotFields("Counter"), "Sum of Counter", xlSum End Sub /* chExcelApplication:Dialog:Dialogsheets("test"):Show. */ chWorkSheet:EnablePivotTable = TRUE. chWorkSheet:PivotTableWizard({&xlDatabase}, "Sheet1!A1:C" + STRING(iColumn), "", "PivotTable1", TRUE, TRUE, TRUE, , , ). /* Define row */ chExcelApplication:ActiveSheet:PivotTables("PivotTable1"):AddFields("Order Qty", "Data", , TRUE). chExcelApplication:ActiveSheet:PivotTables("PivotTable1"):AddFields("Part No", "Data", , TRUE). /* Define data*/ chExcelApplication:ActiveSheet:PivotTables("PivotTable1"):PivotFields("Counter"):ORIENTATION = {&xlDataField}.

  8. ActiveX Controls

  9. ActiveX Controls ActiveX Controls at Work

  10. ActiveX Controls DEF VAR Domain AS CHAR INIT "01" NO-UNDO. /* Program code*/ FOR EACH pt_mstr NO-LOCK WHERE pt_domain = Domain AND pt_part_type = "fab" AND pt_prod_line = "11" AND (pt_ord_qty >= 15000 AND pt_ord_qty <= 30000) : DISPLAY pt_part pt_ord_qty . END. /*FOR EACH pt_mstr*/

  11. ActiveX Controls DEF VAR Domain AS CHAR INIT "01" NO-UNDO. /* Program code*/ FOR EACH pt_mstr NO-LOCK WHERE pt_domain = Domain AND pt_part_type = "fab" AND pt_prod_line = "11" AND (pt_ord_qty >= 15000 AND pt_ord_qty <= 30000) : DISPLAY pt_part pt_ord_qty . END. /*FOR EACH pt_mstr*/

  12. ActiveX Controls DEF VAR Domain AS CHAR INIT "01" NO-UNDO. Additional variables: DEF NEW SHARED VAR chExcelApplication AS COM-HANDLE. DEF NEW SHARED VAR chWindow AS COM-HANDLE. DEF NEW SHARED VAR chWorkbook AS COM-HANDLE. DEF NEW SHARED VAR chWorksheet AS COM-HANDLE. DEF VAR iColumn AS INT INITIAL 1. DEF VAR cColumn AS CHAR NO-UNDO. DEF VAR xlfilename AS CHAR NO-UNDO. Excel include file: {XL5EN32.i}

  13. ActiveX Controls Launch Excel /*Define filename*/ xlfilename = "c:\Test.xls". /* create a new Excel Application object */ CREATE "Excel.Application" chExcelApplication. Setting the chExcelApplication to the Object application /* Launch Excel so it is visible to the user */ chExcelApplication:Visible = TRUE. Setting the visible property to the display the application /* create a new Workbook */ chWorkbook = chExcelApplication:Workbooks:Add(). Setting the chWorkbook to the Object application /* get the active Worksheet */ chWorkSheet = chExcelApplication:Sheets:Item(1). Setting the chWorkSheet to the Object application /* Set the column names */ chWorkSheet:Range("A1"):Value = "Part No". chWorkSheet:Range("B1"):Value = "Order Qty"

  14. ActiveX Controls /* Program code*/ FOR EACH pt_mstr NO-LOCK WHERE pt_domain = Domain AND pt_part_type = "fab" AND pt_prod_line = "11" AND (pt_ord_qty >= 15000 AND pt_ord_qty <= 30000) : /*Output*/ iColumn = iColumn + 1. cColumn = STRING(iColumn). /* Set column values - use of field names*/ chWorkSheet:Range("A" + cColumn):Value = pt_part. chWorkSheet:Range("B" + cColumn):Value = pt_ord_qty. END. /*FOR EACH pt_mstr*/

  15. ActiveX Controls /* Program code*/ FOR EACH pt_mstr NO-LOCK WHERE pt_domain = Domain AND pt_part_type = "fab" AND pt_prod_line = "11" AND (pt_ord_qty >= 15000 AND pt_ord_qty <= 30000) : /*Output*/ iColumn = iColumn + 1. cColumn = STRING(iColumn). /* Set column values - use of field names*/ chWorkSheet:Range("A" + cColumn):Value = pt_part. chWorkSheet:Range("B" + cColumn):Value = pt_ord_qty. END. /*FOR EACH pt_mstr*/

  16. ActiveX Controls Format WorkSheet: /* Set the column width */ chWorkSheet:Columns("A"):ColumnWidth = 12. chWorkSheet:Columns("B"):ColumnWidth = 9.5. /* Set the column formats */ /* "@" = text, date = mm/dd/yy;C, units = #,###, dollars = $#,### */ chWorkSheet:Range("A1:B1"):Font:Bold = TRUE. chWorkSheet:Range("B1:B1"):Font:Italic = TRUE. chWorkSheet:Range("A:B"):FONT:Size = 10. chWorkSheet:Range("A1:B1"):FONT:Size = 12. chWorkSheet:Range("A1:A1"):Interior:ColorIndex = 36. chWorkSheet:Range("B1:B1"):Interior:ColorIndex = 37. chWorkSheet:Range("A:A"):NumberFormat = "@". chWorkSheet:Range("B:B"):NumberFormat = "#,##0".

  17. ActiveX Controls /* Freeze panes */ chWorkSheet:Range("E2"):Activate. chWindow = chExcelApplication:Windows:Item(1). chWindow:FreezePanes = TRUE. /* Turn Autofilter On */ chWorkSheet:COLUMNS("A:A"):AutoFilter(1,,,,TRUE).

  18. ActiveX Controls /* Freeze panes */ chWorkSheet:Range("E2"):Activate. chWindow = chExcelApplication:Windows:Item(1). chWindow:FreezePanes = TRUE. /* Turn Autofilter On */ chWorkSheet:COLUMNS("A:A"):AutoFilter(1,,,,TRUE).

  19. ActiveX Controls Pivot Tables

  20. ActiveX Controls Pivot Table: /* chExcelApplication:Dialog:Dialogsheets("test"):Show. */ chWorkSheet:EnablePivotTable = TRUE. chWorkSheet:PivotTableWizard({&xlDatabase}, "Sheet1!A1:C" + STRING(iColumn), "", "PivotTable1", TRUE, TRUE, TRUE, , , ). /* Define row */ chExcelApplication:ActiveSheet:PivotTables("PivotTable1"):AddFields("Order Qty", "Data", , TRUE). chExcelApplication:ActiveSheet:PivotTables("PivotTable1"):AddFields("Part No", "Data", , TRUE). /* Define data */ chExcelApplication:ActiveSheet:PivotTables("PivotTable1"):PivotFields("Counter"):ORIENTATION = {&xlDataField}.

  21. ActiveX Controls

  22. ActiveX Controls /* Set the column formats */ chExcelApplication:ActiveSheet:Range("A:B"):NumberFormat = "@". chExcelApplication:ActiveSheet:Range("A:A"):FONT:Size = 12. chExcelApplication:ActiveSheet:Range("B:C"):FONT:Size = 10. chExcelApplication:ActiveSheet:Range("A1:A21"):Interior:ColorIndex = 36. chExcelApplication:ActiveSheet:Columns("A:A"):ColumnWidth = 20. chExcelApplication:ActiveSheet:Range("B:B"):FONT:ColorIndex = 12. chExcelApplication:ActiveSheet:Range("B:B"):FONT:Bold = TRUE. chExcelApplication:ActiveSheet:Range("B:B"):Font:Italic = TRUE. chExcelApplication:ActiveSheet:Columns("B:B"):ColumnWidth = 15. chExcelApplication:ActiveSheet:Range("C:C"):FONT:ColorIndex = 3. chExcelApplication:ActiveSheet:Range("C:C"):NumberFormat = "#,##0.00000000".

  23. ActiveX Controls

  24. ActiveX Controls Charts

  25. ActiveX Controls

  26. ActiveX Controls

  27. ActiveX Controls Resources • Windows Constants Include (by T. Bergman) http://www.oehive.org/project/TypeLibConstants • MSDN Office Development http://msdn.microsoft.com/en-us/library/bb726434.aspx • “Using Excel Visual Basic for Applications – Special Edition” (by Jeff Webb) 1996 QUE Publishing/Second Edition ISBN: 0-7897-0269-x

  28. ActiveX Controls Thank You…. Chris Gillespie cgillespie@pridgeonandclay.com Jerry Beaverson jbeaverson@pridgeonandclay.com
