  1. COMPONENTS OF CI AGENT OIL STOP VALVE • Inner Core of Slotted PVC Pipe from 2”OD to 18”OD • Lengths up to 6 feet can be coupled together to accommodate any total length needed

  2. COMPONENTS OF CI AGENT OIL STOP VALVE • Flanges • Wye’s • Double Wye’s • Couplings • Elbow/Bends • Bushings, Reducers, & Any Other PVC Fitting

  3. COMPONENTS OF CI AGENT OIL STOP VALVE • CI Agent Sleeve Slides Over Slotted PVC Pipe • Rubber Portion of CI Agent Sleeve Attaches to PVC Fitting Using Stainless Steel Clamps

  4. EXAMPLES OF CI AGENT OIL STOP VALVES

  5. EXAMPLES OF CI AGENT OIL STOP VALVES

  6. BETHEA TOOL & EQIPMENT COMichael GudgerPh# 770-436-6386Fx# 770-436-9743e-mail: msgudger@bellsouth.nethttp://www.betheatool.com
