Electron Arrangements

Electron Arrangements. Lewis Dot Structures. Learning Objectives Express the arrangement of electrons in atoms using Lewis valence electron dot structures. Electron Arrangements. Valence electron – an electron in an atom’s highest occupied energy level

barton
Download Presentation

Electron Arrangements

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Electron Arrangements Lewis Dot Structures

  2. Learning Objectives • Express the arrangement of electrons in atoms using Lewis valence electron dot structures • Electron Arrangements

  3. Valence electron – an electron in an atom’s highest occupied energy level • Outermost electrons of the electron cloud • Establish chemical characteristics of elements • Only electrons shown in Lewis electron dot structures • Symbolized as dots • Lewis Dot Structures

  4. Number of valence electrons is the same as the group number for representative elements • Lewis Dot Structures

  5. Helium is an exceptionbecause its highest occupied energy level can only hold two electrons • Lewis Dot Structures

  6. Number of valence electrons determines behavior • Elements in the same group have similar chemical properties • Lewis Dot Structures

  7. Drawing an Electron Dot Structure Step 1 Step 2 • Identify the symbol for the element and its number of valence electrons using the periodic table. • Place the corresponding number of electron dots around the symbol. Imagine that the symbol has four sides: top, right, bottom, and left. Begin by assigning one dot per side, moving clockwise around the symbol. Then, if there are still more dots to assign, start adding a second dot to each side until all of the valence electrons have been accounted for.

  8. Drawing an Electron Dot Structure Step 1 Step 2 Does the result make sense? Ex) Draw the electron dot structure for phosphorus. • Identify the symbol for the element and its number of valence electrons using the periodic table. • The symbol for phosphorus is P. Phosphorus is in group 5A so it has 5 valence electrons. • Place the corresponding number of electron dots around the symbol. Imagine that the symbol has four sides: top, right, bottom, and left. Begin by assigning one dot per side, moving clockwise around the symbol. Then, if there are still more dots to assign, start adding a second dot to each side until all of the valence electrons have been accounted for. Yes.

  9. Learning Objectives • Express the arrangement of electrons in atoms using Lewis valence electron dot structures • Electron Arrangements
