1. Rackonomics and Network Virtualization BLADE Network Technologies

2. What’s New? Virtual Cooler Easier • BLADE: The leader in blade networking • BLADE’s contribution to “Rackonomics” is the answer to network overload • Extends virtualization: Mirrors benefits of server virtualization within the network at the rack level • Saves Energy: Optimized airflow for servers and storage racks • Painless: Removes complexity through simplified management and fabric convergence BLADE Network Technologies BLADE is the world’s first provider of rack-level network virtualization

3. Who is BLADE? A market-leading supplier of Gigabit and 10G Ethernet networking infrastructure solutions that reside in: Blade servers “Scale-out” server racks Storage racks 45% blade networking market share #1 server vendor in Japan #1 server vendor in Japan #1 server vendor worldwide #1 blade server vendor worldwide BLADE Network Technologies

4. Field-proven Layer 2/3 switch With SmartConnect™ and VMready™ software Optional Layer 4–7 products BLADEHarmony™ Manager Converged Enhanced Ethernet-ready switches Large network experience – 12,000 switches in one installation BLADE products are in half of the Fortune 500 Companies BLADE Experience Connecting to over 825,000 servers! ~186,000 switches (4.3 million ports) and counting Experienced in server & storage optimized switching BLADE Confidential 4

5. Growing Pressures on Data Centers The answer is Rackonomics BLADE Network Technologies Multiple fabrics Virtualization Multicore CPUs Scale-out Web 2.0 Consolidation Clustering Power & cooling Management complexity

6. Rackonomics 101 Virtual Cooler Easier BLADE Network Technologies • Rack-level provisioning makes it easier to design for scale out • With Rackonomics, IT can: • Respond faster to business demands • Increase energy efficiency • Decrease TCO

7. Rack-level Server Provisioning is the New Approach! The Replicated Rack is the New Data Center! BLADE Network Technologies

8. Industry First:BLADE’s Rack-level Network Virtualization Virtual Cooler Easier RackSwitch G8000 1/10G Ethernet Switch RackSwitch G8100 10G Low Latency Switch BLADE Network Technologies • Networking Virtualization switch-resident software • SmartConnect™: Worlds first rack-level network virtualization • VMready™: Removes stress on network caused by virtualization (e.g. migrating network security policies) • First server and storage rack-optimized switch • Airflow to match server and storage racks • Makes networks easier to manage • BLADEHarmony™ Manager • Converged fabric support (CEE / DCE)

9. BLADE RackSwitchDesigned for IBM iDataPlex • April 23, 2008 – IBM enters the Rackonomics market • Same day as BLADE RackSwitch • RackSwitch & iDataPlex – A perfect fit • Airflow matches server airflow • Up to 8 RackSwitches supported • Other vendors limited to 4 switches due to need for expensive air baffles BLADE Network Technologies 1-Apr-14 9

10. Rack Virtualization =Virtual, Cooler, Easier Networking BLADE RackSwitches Rack with Virtualized Network Virtualization Software (SmartConnect™ & VMready™) BLADEHarmony™ Manager BLADE Embedded Switches BLADE Network Technologies

11. VirtualSmartConnect™ Virtualization Software Share I/O across a blade chassis or rack Improved fault-tolerance Decouple scaling of CPU, I/O and storage Server-centric products Networking optimized for server administrators Used today by: Large retailer Large Wall Street financial firm Leading Web 2.0 service Web traffic Video traffic Backup traffic BLADE Network Technologies

12. Enable VM movement across a blade chassis or rack Moves network and security policies with the virtual machines Complementary to virtualization-optimized NICs VirtualVMready™ Virtualization Software } VM1 Web Traffic VM2 VMready™ } VM3 VM4 Video Traffic } VM5 VM6 Backup VM7 VM8 BLADE Network Technologies 1-Apr-14 12

13. CoolerAirflow Designed for Server & Storage Racks Cool Air Hot Air Hot Air Switch RackSwitch Pre-heated Air Hot Air Server Server Server Server Server Server Server Server • Majority of network products in server racks would create “hot loops” in airflow • BLADE RackSwitches allow for “cool aisles” and “hot aisles” • US Patent application for “redirection of airflow” Traditional Switch BLADE RackSwitch BLADE Network Technologies

14. Easier BLADEHarmony™ Manager Software • Data center view and management of I/O • Single-click update to thousands of switches • Integrates with HP Systems Insight Manager & IBM Director BLADE Network Technologies

15. EasierSaves Time = Money Time Savings for Software Upgrades & Data Collection Over Three Years. Example: 1,000 devices • Easy scheduling of updates/upgrades • Centralized point of administration • Automatic switch discovery • Time saving management tools 8X Faster with BLADEHarmony! www.bladenetwork.net

16. EasierFabric Convergence with 10G Ethernet • Lossless with Converged Enhanced Ethernet (CEE) • IP SAN (NAS, iSCSI) and Fibre Channel over Ethernet (FCoE) • Low latency for high-performance clusters (HPC) • Low power with fewer components • Low cost • Single attach (NIC/Adapter) for servers & storage • Reduced cabling & management SAN, LAN, and Cluster traffic will converge on 10G Ethernet SAN Fibre Channel Ethernet LAN HPC Cluster InfiniBand Converged Server Fabric • NAS and iSCSI – Available today • FCoE-ready lossless fabric – demo at SNW & Interop 2008 BLADE Network Technologies

17. 48 ports, Gigabit Ethernet with 10G Uplinks Top of Rack, 1U 44 ports 1G, RJ-45 copper 4 ports 1G, SFP fiber 4 ports 10G, CX4 or SFP+ for uplinks Air flow optimized for hot-aisle / cold aisle server / storage racks Under $500 per 10G port (US list) 24 ports, 10 Gigabit Ethernet Top of Rack, 1U 20 ports CX4 – the proven lowest latency 4 ports SFP+ for fiber uplinks Low latency – 300 nsec Patented CX4 cable retainer solves cable issues Air flow optimized for hot-aisle / cold aisle server / storage racks Virtual Cooler Easier RackSwitch Ethernet Switches RackSwitch G8000 1/10G Ethernet Switch RackSwitch G8100 10G Low Latency Switch $5,495 US list $11,950 US list BLADE Network Technologies

18. Extends BLADE’s expertise into rack networking Field-proven, mature switch software Existing (IBM, HP, NEC) and new distribution partners Over half of Fortune 500 count on BLADE “Rackonomics” through virtualized networking RackSwitch products for scale-out networks Virtual Cooler Easier BLADE is First with Rack-level Network Virtualization BLADE Network Technologies
