  1. Chromosomes

  2. Human Chromosomes • Human cells have 23 pairs of chromosomes (homologous pairs) for a total of 46. • One member of each pair comes from the sperm and the other from the egg. • Each chromosome in the homologous pair will contain the same genes (possibly different alleles)

  3. Mitosis

  4. Mitosis • Mitosis is the process in which a cell duplicates its chromosomes and divides to generate two identical cells. • Occurs when organisms grow (ie from a zygote to adult) and also in wound healing. (growth and repair) • Happens throughout the body, but particularly in bone marrow, skin, hair and nails.

  5. Sequence of Events • Before mitosis occurs, DNA must replicate. • Chromatin in the nucleus begins to condense and becomes visible as chromosomes. Chromosome Chromatin

  6. The Mitosis Process

  7. Sequence of Events • Each chromosome forms an identical pairthat remains attached at theCentromere. Centrioles begin moving to opposite ends of the cell. • The nuclear membrane dissolves as centrioles send out spindle fibres to attach to the centromeres.

  8. Centromere Unduplicated Duplicated

  9. Sequence of Events • Spindle fibres align the chromosomes along the middle of the cell nucleus. • The paired chromosomes separate at the centromere and move to opposite sides of the cell. • Chromosomes arrive at opposite poles and the cell begins to divide into two.

  10. 46 chromosomes

  11. 92 chromosomes

  12. 46 chromosomes 46 chromosomes +

  13. Mitosis

  14. Mitosis
