Mechanical Systems

Mechanical Systems. Topic 1 - Levers and Inclined Planes. Lever A simple machine that changes the amount of force you need to move an object Parts of a lever Fulcrum – The fixed point that is the lever’s point of rotation Effort Force – The force you exert on a lever to make it move

giza
Download Presentation

Mechanical Systems

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Mechanical Systems

  2. Topic 1 - Levers and Inclined Planes Lever • A simple machine that changes the amount of force you need to move an object Parts of a lever • Fulcrum – The fixed point that is the lever’s point of rotation • Effort Force – The force you exert on a lever to make it move • Load – The mass of an object moved or lifted by the lever

  3. Three Classes of Levers • Class 1 Lever – The fulcrum is between the effort and the load • Class 2 Lever – The load is between the effort and the fulcrum • Class 3 Lever – The effort is between the fulcrum and the load

  4. Examples of Levers Class 1 Levers – A see – saw, hammer, scissors, pliers, trolley, crowbar Class 2 Levers – Bottle opener, stapler, wheelbarrow, nail clippers, nutcracker Class 3 Levers – Fishing rod, tweezers, tongs, hockey stick

  5. Take a break

  6. Inclined Planes An inclined plane is a ramp or a slope that reduces the force you need to lift something. • Inclined planes and levers reduce the work you do to move an object.

  7. Topic 2 – The Wheel and Axle, Gears and Pulleys The Wheel and Axle Wheels and Axles are also simple machines that provide a mechanical advantage. Examples:

  8. Gears A simple machine that consists of a wheel with teeth that is used to reduce work. Pulleys A simple machine consisting of a grooved wheel with a rope or chain running through the groove. These are used to make work more convenient and even reduce work. • Pulleys can be fixed or movable • Complex pulley systems are used to move very heavy loads

  9. Take a break
