Sine Bar

Sine Bar. Primary use Positioning precision angles For mill, grinder, stenciling 4 steps Locate tools: Sine Bar : Cabinet 5 Gage Blocks : Cabinet 5 Calculate which gage block to use Sine Bar is 5 inches center to center

hammer
Download Presentation

Sine Bar

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Sine Bar • Primary use • Positioning precision angles • For mill, grinder, stenciling • 4 steps • Locate tools: • Sine Bar: Cabinet 5 • Gage Blocks: Cabinet 5 • Calculate which gage block to use • Sine Bar is 5 inches center to center • Using calc take 5 * Sin ( θ ) this is the gage block or blocks that will be used. • Create triangle • Use Sine Bar as Hypotenuse • Using gauge blocks as height • Construct a 90º triangle • Set-up machines • Using sine bar as a parallel bar set work piece in mill clamps then remove sine bar and continue • Use sine bar set-up as a stencil on your work piece • Use sine bar as a plane for your work piece on the grinder

  2. Locate Pictures Calculate Setup Create
