PHYLUM ANNELIDA

PHYLUM ANNELIDA. Phylum Annelida- Class Polychaeta: parapodium w/ setae & acicula. Parapodia are used for locomotion, sensory & respiration. [fig 6.3-A]. Phylum Annelida- Class Polychaeta. Polychaete dissection. Note esophageal caeca and

jenaya
Download Presentation

PHYLUM ANNELIDA

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. PHYLUMANNELIDA

  2. Phylum Annelida- Class Polychaeta: parapodium w/ setae & acicula. Parapodia are used for locomotion, sensory & respiration. [fig 6.3-A]

  3. Phylum Annelida- Class Polychaeta. Polychaete dissection. Note esophageal caeca and muscular pharynx. Remember, polychaete worms have parapodia (which look like “fins”) [fig 6.4]

  4. Phylum Annelida- Class Oligochaeta: note typhlosole (increases surface area to aid in digestion). [fig 6.8]

  5. Phylum Annelida- Class Oligochaeta: close-up of intestine w/ typhlosole. [fig 6.8]

  6. Phylum Annelida- Class Oligochaeta: note longitudinal & circular muscles, nephridium, and the coelom. [fig 6.8]

  7. Phylum Annelida- Class Oligochaeta. Earthworm dissection[fig 6.7]

  8. Phylum Annelida- Class Hirudinea. B A View of both preserved organism (A) and slide of whole mount (B). Note segmentation, as well as the 2 suckers found in all leeches. Remember all leeches are not blood-suckers. [fig 6.9]
