Single Spring Mechanical Seals These Mechanical Seals area unit having single spring style to require care contaminated liquids. thanks to open volute spring, it's used for non-clogging and self-cleaning operations. With durable and significant long spring, it will beware of mis-alignment, vibrations, thermal expansions & axial play of shaft. These Seals will be offered in Un-balance also as Balance style to require care kind of applications. These Mechanical Seals area unit economical and straightforward to put in and maintain thanks to lesser elements. Single Spring Mechanical Seals will be created for Uni or Bi-direction motion of shaft. we've nice selection during this style to suit any applications. http://www.mechseal.com/ Application : Viscous, Abrasive, Crystallizing, Solidifying & Non-Corrosive Slurry. Operating Limits : Pressure : 7 bar for Un-balance & 40 bar for Balance Seals Temperature : -30°C to 250°C Speed : 20 m/s Sizes : 12 mm to 200 mm Materials : Faces : Carbon, Silicon Carbide, Tungsten Carbide, Ceramic, Cr. Steel. Elastomers : PTFE, Perflouro, Viton, Aflas, EPDM, Nitrile, Silicon Hardware : SS-316, Hastelloy-C, Alloy-20, Titanium
