  1. Female Reproductive System Laboratory Orientation

  2. From Netter

  3. #239 Monkey Ovary Cortex Medulla Tunica albuginea Germinal epithelium

  4. #239 #269 Primordial follicle Primary follicle Secondary follicles

  5. #269 Graafian follicle ? Secondary follicle

  6. Theca interna Cumulus oophorus Theca externa #269 Zona pellucida oocyte Corona radiata

  7. #236a & 235 Antrum A: Granulosa cells B: Theca interna C: Theca externa C B A

  8. #236a Corpus Luteum Granulosa lutein cells Theca lutein cells Granulosa lutein cells

  9. #239 Early stages of atretic follicles

  10. #239 Atretic follicles with thickened basement (glassy) membranes. Also, #234 & #234-2

  11. #236a Also, #234 (H&E) & #234-2 (trichrome) early Corpus albicans Late

  12. #240-1: Infundibulum #240-2: Ampulla #241odd: Intramural #241even: Isthmus

  13. Ciliated and non-ciliated cells

  14. Oviduct Seminal vesicle

  15. Oviduct with ciliated and nonciliated cells cells Seminal vesicle with simple columnar secretory cells

  16. #244 Proliferative endometrium

  17. #244 Spiral and straight arteries (arterioles)

  18. #243 Early (very early) secretory endometrium

  19. #245-1 Secretory (early) endometrium

  20. Early and late secretory phase ( basal accumulation of glycogen) (“saw tooth” appearance) Saw tooth appearance Glycogen in lighter staining basal cytoplasm

  21. #245-2 Menstrual endometrium

  22. Secretory endometrium Prostate gland

  23. Netter #366B Internal Os Cervical canal with palmate folds Vaginal fornix External Os Vagina

  24. Uterine Cervix #249 A: Stratocolumnar Junction B A UCSF #405 B: Cervical (mucosal) glands Nabothian cyst

  25. #250-1 Vagina H&E Vaginal epithelium Note the empty appearance of the cells due to extraction of stored glycogen in cells #250-2 Vagina Trichrome

  26. #261 Active mammary gland #259 Inactive mammary gland

  27. #258 Active mammary gland Note: Loose and cellular (abundant plasma cells) intralobular connective tissue as compared to dense interlobular c.t.

  28. Slide 258 (active mammary gland, H&E) secretory epithelium (note apical glycogen and lipid) Plasma cells (in intralobular tissue)

  29. Slide 258 (active mammary gland, H&E) myoepithelial cells secretory epithelium
