Patent Ductus Arteriosus

Patent Ductus Arteriosus. Seoul National University Hospital Department of Thoracic & Cardiovascular Surgery. Patent Ductus Arteriosus. 1. Definition An open communication usually between upper descending aorta and proximal portion of left pulmonary

matana
Download Presentation

Patent Ductus Arteriosus

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Patent Ductus Arteriosus Seoul National University Hospital Department of Thoracic & Cardiovascular Surgery

  2. Patent Ductus Arteriosus • 1. Definition • An open communication usually between upper • descending aorta and proximal portion of left pulmonary • artery and is the result of persistent patency of fetal • ductus arteriosus • 2. History • * Galen : 1st description(Born in AD131) • * Gibson : Continuous murmur in 1900 • * John Strieder : Attempted to close in 1937 • * Robert E. Gross : Successful ligation in 1938 • * Rashkind & Cuaso : Catheter closure in 1977

  3. Pathophysiology of PDA • Left-to-right shunt from the thoracic aorta to the pulmonary artery leads to augmented pulmonary blood flow, pulmonary hypertension, and congestive heart failure. • Demonstrating blood from across the ductus with associated left ventricular hypertrophy and left atrial enlargement and comprises 12~15% of congenital heart defects

  4. Anatomy of Ductus Arteriosus • 1. Position • * Unilateral • * Bilateral • * Absence ( 35-40% in TOF ) • 2. Histology of PDA • * Thick intima with unfragmented elastic lamina • * Media contains mucoid material with spiral muscular • intricate helicoid arrangement and elastic material • 3. PDA as a coexisting anomaly • * Orientation of ductus to aortic arch varies

  5. Morphology of Ductus Arteriosus • 1. At birth • * Resembles a muscular artery • * Intima : intact wavy internal elastic lamina, split up • into several layers and interrupted • underneath intimal cushion • * Media : mainly circular smooth muscle cells with • minimal elastic fibers ( mucoid lake ) • 2. Anatomic closure • * Necrosis of cellular component of the media and • diffuse fibrous proliferation of intima • 3. Aneurysms of ductus arteriosus • * Spontaneous infantile form • * Childhood or adult form

  6. PDA Gross Finding PDA

  7. PDA PDA

  8. Postnatal Closure of Ductus Arteriosus • 1. First Stage ( Functional closure ) • * Within 10~15 hours after birth ( contraction of smooth muscle • & approximation of intimal cushion ) • 2. Second Stage (Anatomic closure ) • * Completed by 2~3weeks ( fibrous proliferation of intima, • necrosis of media, hemorrhage in the wall and sealing of • the lumen ) • * Ductus arteriosus is closed by 8 weeks in 88% • 3. Physiology • * Vasoactive substances ( acetylcholine, bradykinin, endogenous • catecholamine and others ) by variations in PH, but chiefly by • 02 tension and prostaglandins ( PGE1, PGE2, prostacyclin, • PGI2 )

  9. Natural History of PDA • 1. Incidence • * Isolated PDA : 1/2000 birth, 5-10% of CHD • * Sex ratio ; male : female = 1 : 2 • 2. Spontaneous closure • * 0.6% of patients per year. ( 20% by age of 60 ) • * Uncommon over 3~5 months of age ( full term baby ) • 3. Death • * Untreated large PDA is high in infancy ( 30%) • * 42% of patients with PDA will die by age of 45 • 4. Mode of Death • * CHF in infancy • * CHF by 2nd or 3rd decade in large PDA ( PVR ) • * CHF 3rd or 4th decade in moderate PDA • * Rare SBE

  10. Clinical Features of PDA • 1. Large PDA • * Severe congestive heart failure within a month • * Tachypnea, sweating, irritability, poor feeding, • 2. Moderate PDA • * Large shunt from the 2nd or 3rd months of age • * Compensatory LVH with improvement & stabilization • 3. Small PDA • * Symptoms are absent in infancy and childhood • * Continuous murmur • 4. Silent PDA • * Controversial in surgical treatment

  11. Operation of PDA • 1. Indication • 1) Large PDA is indicated beyond the 1st month of life, but • symptoms of heart failure is present, surgery is indicated • 2) In the absence of symptom, operation delayed until • the age of about 6 months • 2. Contraindication :severe pulmonary vascular disease • 3. Technique of operation • 1) Division :divided rather than ligation • 2) Ligation : In neonate or some infant • 3) Closure of PDA in older adults • * Using CPB (calcified aortic end, short ductus, PH) • 4. Percutaneous closure ( Rashkind, Amplatzer, Coil ) • 5. Thoracoscopic closure

  12. Anatomy of PDA • PDA as visualized from a left anterior oblique view

  13. PDA Exposure

  14. Operative Exposure of PDA • PDA through a left thoracotomy & the mediastinal pleura • is opened and reflected anteriorly and posteriorly

  15. Median Approach of PDA • Closure of PDA from a median sternotomy approach

  16. PDA Ligation

  17. PDA Division

  18. Thoracoscopic Surgery (VATS) • Indications Isolated PDA associated with or without other minor cardiac lesions • Contraindications Complex congenital defects requiring CPB Ductus diameter larger than 9 mm Calcification of ductus Pleural adhesion or right aortic arch

  19. Thoracoscopic Surgery (VATS) • Why VATS PDA ligation -- Potential thoracotomy morbidity Long-term post-thoracotomy pain Postoperative pulmonary complication Thoracic scoliosis -- VATS PDA ligation Decrease chest wall trauma Minimize nerve injury & rupture of intercostal ligament Cosmetic effect Painless

  20. PDA Ligation by VATs • An endoscopic vascular clip is placed to interrupt • the patent ductus arteriosus. The arrow denotes • the recurrent laryngeal nerve

  21. Operative Results of PDA 1) Mortality 2) Incremental risk factors for early death * old age • * pulmonary vascular disease • 3) Survival • 4) Symptomatic and functional status • 5) Physical development • 6) Recurrence • 7) False aneurysm • 8) Vocal cord paralysis 9) Phrenic nerve paralysis 10) Chylothorax

  22. Management of Pre-term PDA • General management Fluid restriction Ventilatory support Correction of anemia Correction of metabolic acidosis Diuretics; lasix decrease ECF volume, but increase prostaglandin production • Indomethacin • Other cyclooxygenase inhibitor Ibuprofen Mefenamic acid • Surgical treatment

  23. PDA in Pre-term Baby (1) 1. Incidence • Increase with decreasing gestational age & birth weight, • but hemodynamic significancy is less. • 28 ~ 30wks : 77% Wt under 1000gr : 40% • 31 ~ 33wks : 44% Wt under 1750gr : 10% • 34 ~ 36wks : 21% • 2. Operative indications • Failure of indomethacin trial • Respiratory distress • Necrotizing enterocolitis • Intracranial hemorrhage

  24. PDA in Pre-term Baby (2) • 3. Operative results • Early mortality : 10~30% • Respiratory distress • Intracranial hemorrhage • Diffuse coagulopathy • Late : BPD in 1/3 of survivor • Complications (CP, retrolental fibroplasia) • in 1/6 of survivor
