  1. Sheet Packs P&O Ferrymasters Driver Training Programme 2019 v1 TSE Ref - LRG-0015-SP low friction Sheet packs Issue 1

  2. or LC 2000 daN Essential Requirements • Trailer Headboard – EN 12642 • Code L or equivalent 10t • Code XL or equivalent 28t • Stanchion Posts • 80 x 80 x 5 mm 10t • 100 x 100 x 4 mm 28t • Straps • 12 straps with forward blocking • 34 Edge Protection +

  3. Strapping – opposing loops / ‘strangle strapping’ + P or

  4. 8 x LC 2000 daN 28 x Strapping – opposing loops / ‘strangle strapping’ +

  5. 7 x LC 2000 daN 24 x Restraining a Pyramid load Restraining a Pyramid load + • 1. Block it all forwards • 2.Secure the top pack sideways 3. Secure the top pack rearwards - this will clamp the lower packs in place

  6. 30 x 10 x LC 2000 daN Basic principles – add rear restraint 1 Forward - Blocked (posts, headboard, cross-over straps) 2 Sideways - Strangle strapped 3 Rearwards - Strapped + Direction of travel The driver and the public are now safe! 6

  7. 9 x LC 2000 daN 34 x Cross-over strap option + Front of stack aligned • Forward – 2 Cross-over straps • Sideways – Strangle strapped • Rearwards – 2 Cross-over straps

  8. 12 x LC 2000 daN 32 x ‘H’ frame system + Front of stack aligned • Forward – Timber H-frames with 2 straps • Sideways – Strangle strapped • Rearwards – Timber H-frame with 2 straps
