  1. Naval Sea Power

  2. Aircraft Carrier CVN Nimitz-class

  3. Multi-purpose Aircraft Carrier CV Multi-purpose Aircraft Carrier CVN (Nuclear-Propulsion)

  4. Builder Newport News Shipbuilding Co., Newport News, Va. Power Plant Two Nuclear Power Plant (A4W Pressurized Water Reactor)Four shafts, Four propellers, with five blades each Length, overall 1,092 feet (332.85 meters) Displacement Approx. 97,000 tons (87,300 metric tons) full load Speed 30+ knots Aircraft 85 Catapults Four Crew Ship's Company: 3,200Air Wing: 2,480

  5. Battleship BB - IOWA-class

  6. Displacement: 57271 tonsDead Weight: 12040 tons Length Overall Length: 888 ftMax Speed 35 knots Power Plant Eight boilers, four geared turbines, four shafts, 212,000 shaft horsepower

  7. Armament 32 - Tomahawk ASM/LAM - 8 armored box launchers16 - Harpoon ASM - 4 quad cell launchers   9 - Mk   7 - 16-inch / 50 caliber guns12 - Mk 28 - 5-inch / 38 caliber guns  4 - Mk 15 - 20mm Phalanx CIWS Compliment 1,515 ship's company65 officers1,450 enlisted58 Marines

  8. Guided Missile Cruiser CGN BAINBRIDGE class

  9. Guided Missile Cruiser CG Guided Missile Cruiser CGN (Nuclear-Propulsion)

  10. Displacement: 9265 tons Length Overall Length: 565 ftWaterline Length: 550 ft Max Speed 30-plus knots Power Plant 2 - D2G General Electric pressurized, water-cooled reactors2 geared turbines, 2 shafts @ 60,000shp each

  11. Armament Standard Missiles (ER)ASROC (from MK 16 box launcher)8 - Harpoon (from two quad launchers)8 - Tomahawk ASM/LAM (from 2 armored box launchers6 - MK 46 torpedoes (from 2 triple tube mounts)2 - 20mm Phalanx CIWS Electronic Warfare SLQ-32 Complement 558 (42 officer, 516 enlisted)

  12. Destroyers DD Arleigh Burke -class

  13. Destroyer DD Guided Missile Destroyer DDG

  14. Builder: Bath Iron Works, Northrop Grumman Ship Systems Propulsion: Four General Electric LM 2500-30 gas turbines; two shafts, 100,000 total shaft horsepower. Length: 505 feet Beam: 59 feet (18 meters).

  15. Displacement: 9,496 tons. Speed: In excess of 30 knots. Crew: 276 Armament: Standard Missile (SM-2MR); Vertical Launch ASROC (VLA) missiles; Tomahawk®; six MK-46 torpedoes (from two triple tube mounts); Close In Weapon System (CIWS), 5” MK 45 Gun, Evolved Sea Sparrow Missile

  16. Frigates FFG OLIVER HAZARD PERRY-class

  17. Frigate FF Missile Frigate FFG

  18. Power Plant 2 - General Electric LM 2500 gas turbine engines1 shaft, 41,000 shaft horsepower total. Length Short: 445 feet Displacement 4,100 tons (full load) Speed 29 plus knots (33.4+ miles per hour)

  19. Crew ACTIVE: 13 Officers, 287 EnlistedNRF: 83 Active, 76 TAR, 57 SELRES Armament Standard Missile (MR)Harpoon (from Standard Missile Launcher)6 - MK-46 torpedoes(from two MK 32 SVTT triple mounts)1 - 76 mm (3-inch)/62 caliber MK 75 rapid fire gun1 - Phalanx close-in-weapons system

  20. Submarine (Nuclear-Powered) SSN - Las Angeles class

  21. Builder: Newport News Shipbuilding Co.; General Dynamics Electric Boat Division. Date Deployed: Nov 13, 1976 (USS Los Angeles) Propulsion: One nuclear reactor, one shaft Length: 360 feet (109.73 meters) Speed: 25+ knots (28+ miles per hour Crew: 16 Officers; 127 Enlisted Armament: Tomahawk missiles, VLS tubes (SSN 719 and later), MK48 torpedoes, four torpedo tubes.
