A Guide to Managing and Maintaining your PC, 6e

1. A+ Guide to Managing and Maintaining your PC, 6e Chapter 19 Securing Your PC and LAN

2. A+ Guide to Managing and Maintaining your PC, 6e 2 Objectives Learn how to secure a desktop or notebook computer Learn how to secure a local wired or wireless network Learn how malicious software works and how to clean an infected system

3. A+ Guide to Managing and Maintaining your PC, 6e 3 Introduction Topics to cover Methods for protecting computers and networks How to use several security tools How malicious software works A step-by-step plan to remove malicious software

4. A+ Guide to Managing and Maintaining your PC, 6e 4 Securing Your Desktop or Notebook Computer Reasons for providing additional security Protection from attacks within the network Attacks through security loopholes Exposure during travel A few methods for securing a computer Limit use of the administrator accounts Keep Windows updates current Physically protect your equipment Keep good backups of user data Destroy trash that might contain sensitive data

5. A+ Guide to Managing and Maintaining your PC, 6e 5 Access Control Authentication: identifies an individual Authorization: assigns privileges/rights to individuals Types of passwords Power-on passwords (configured in CMOS setup) Windows passwords Online account passwords Application passwords Some rules for creating strong passwords Combine upper/lower case letters, numbers, symbols Do not use words in any language

6. A+ Guide to Managing and Maintaining your PC, 6e 6

7. A+ Guide to Managing and Maintaining your PC, 6e 7 Access Control (continued) Controlling access to a PC using Windows Set a user password for the user account Configure user access to certain files and folders Overview for assigning permissions to file and folder Disable simple file sharing from View in Folder Options Open Properties window of a folder and select Sharing Click Permissions and select options Protected files and folders display authentication box Cacls: command for configuring file and folder access

8. A+ Guide to Managing and Maintaining your PC, 6e 8

9. A+ Guide to Managing and Maintaining your PC, 6e 9 Limit Use of the Administrator Account Three common types of accounts in Windows Administrator Guest Limited User Advice for protecting the Administrator Account Create a Limited User account for ordinary activities Use Administrator account for reserved activities Change appearance of desktop to flag the account Change strong password on a regular basis

10. A+ Guide to Managing and Maintaining your PC, 6e 10 Use a Personal Firewall Firewalls are implemented in software or hardware Purpose of a firewall Prevent worms or hackers from invading your system Turn on Windows Firewall to protect your system It may be configured to allow for exceptions Windows Firewall is included with Service Pack 2

11. A+ Guide to Managing and Maintaining your PC, 6e 11

12. A+ Guide to Managing and Maintaining your PC, 6e 12 Use AV Software Antivirus (AV) software protects system from viruses Using AV software to greatest effect Configure software to automatically download updates Run AV software as a background process Set software to automatically scan e-mail attachments Virus signature: distinguishing characteristics of virus AV software does not always stop adware or spyware Use removal program for adware or spyware Example: Ad-Aware by Lavasoft (www.lavasoft.com)

13. A+ Guide to Managing and Maintaining your PC, 6e 13

14. A+ Guide to Managing and Maintaining your PC, 6e 14 Keep Windows Updates Current Causes for Windows susceptibility to attacks Popularity of system makes it an attractive target Highly integrated components give many entry points Update Web site: windowsupdate.microsoft.com Two ways to keep updates current Access Web site from Windows Update Run automatic update utility as background process

15. A+ Guide to Managing and Maintaining your PC, 6e 15

16. A+ Guide to Managing and Maintaining your PC, 6e 16 Set Internet Explorer for Optimum Security Some security features in Internet Explorer Pop-up blocker The ability to manage add-ons The ability to block scripts The ability to disable scripts embedded in Web pages The ability to set the general security level Medium is recommended

17. A+ Guide to Managing and Maintaining your PC, 6e 17

18. A+ Guide to Managing and Maintaining your PC, 6e 18 Use Alternate Client Software Microsoft products targeted by authors of malware Microsoft Internet Explorer Microsoft Outlook Express and Microsoft Outlook Some reasons for susceptibility Popularity Close integration with other Windows components Use of ActiveX controls Alternate browser: Firefox by Mozilla Alternate e-mail client: Eudora by Qualcomm

19. A+ Guide to Managing and Maintaining your PC, 6e 19 Consider Using Microsoft Shared Computer Toolkit for Windows XP Microsoft Shared Computer Toolkit for Windows XP Locks down the drive on which Windows is installed Features of Windows XP that can be locked down Windows configuration Installed software or hardware User settings or user data Some temporary changes are allowed When system reboots, it returns to prior state Toolkit can be downloaded for free

20. A+ Guide to Managing and Maintaining your PC, 6e 20 Hide and Encrypt Files and Folders Windows 2000/XP Encrypted File System (EFS) Works on with Windows 2000/XP NTFS EFS Is not supported in Windows XP Home Edition Encryption: technology for encrypting folders/files Best practice: encrypt at the folder level How to encrypt a file or folder Open Properties window of file or folder Click Advanced and select appropriate options Encrypted folders and files in are displayed in green

21. A+ Guide to Managing and Maintaining your PC, 6e 21

22. A+ Guide to Managing and Maintaining your PC, 6e 22 Hide and Encrypt Files and Folders (continued) Overview for sharing an encrypted file First export your certificate The other user imports certificate for access to file Sharing tool: Certificate Export Wizard Data recovery agent (DRA): can decrypt file/folder Three ways decrypt a file or folder Change encryption attribute from Properties window Move file or folder to a FAT logical drive Use the Cipher command

23. A+ Guide to Managing and Maintaining your PC, 6e 23

24. A+ Guide to Managing and Maintaining your PC, 6e 24 Physically Protect Your Equipment Don’t move or jar your computer when it’s turned on Don’t smoke around your computer If your data is private, keep it under lock and key Keep magnets away from your computer Lock down the computer case

25. A+ Guide to Managing and Maintaining your PC, 6e 25 Beware of Social Engineering Social engineering Tricking people into giving out private information Passing unsafe programs into the network or PC Some techniques of social engineers Phishing: extracting personal data via e-mail Scam e-mail: offers to join phony ventures Virus (e-mail) hoax: clogs up e-mail systems A few rules for using the Internet Do not click links inside e-mail messages Investigate a Web site before downloading software

26. A+ Guide to Managing and Maintaining your PC, 6e 26 Beware of Social Engineering (continued) Two ways to debunk a hoax e-mail Note phrases/subjects that request mass forwarding Use services of security site; e.g., www.hoaxkill.com Scripts: code segments automating set of tasks Example: files with extensions .wsf and .vbs Malicious scripts are often hidden in e-mails Example: the link www.symantec.com.vbs Protecting against malicious scripts Set Windows to display file extensions Set Windows to first load script to Notepad

27. A+ Guide to Managing and Maintaining your PC, 6e 27

28. A+ Guide to Managing and Maintaining your PC, 6e 28

29. A+ Guide to Managing and Maintaining your PC, 6e 29 Keep Good Backups of User Data Prepare for a disaster by making good data backups Refer to Chapter 13 for backup procedures

30. A+ Guide to Managing and Maintaining your PC, 6e 30 Backup System Files Use Ntbackup to back up System State and registry Refer to Chapter 12 for procedures When to back up the System State After you have made major changes to the system Example: after installing a new hard drive Make backups a routine part of monthly maintenance

31. A+ Guide to Managing and Maintaining your PC, 6e 31 Make Use of Event Logging and Incident Reporting Some incidents you might be expected to report An attempt at breaking in to a secured PC or network The security has been broken An alarm has been activated Some reasons for incident reporting The need for others to respond to an incident The need to know about a weak security loophole Legal concerns Monitoring Windows 2000/XP logon events Configure Event Viewer to track failed logon attempts

32. A+ Guide to Managing and Maintaining your PC, 6e 32

33. A+ Guide to Managing and Maintaining your PC, 6e 33 Make Use of Event Logging and Incident Reporting (continued) Monitor changes to files and folders Set the Group Policy to audit an object Add the users that you want to monitor Decide which activity to monitor View logged activity in the Event Viewer Some third-party monitoring tools Autoruns by Sysinternals WinPatrol by BillP Studios Monitoring network activity with Windows Firewall Configure Log Settings accessed from Advanced tab

34. A+ Guide to Managing and Maintaining your PC, 6e 34

35. A+ Guide to Managing and Maintaining your PC, 6e 35 Destroy the Trash Trash is a source of sensitive information How to prevent the exposure of data Destroy all storage media before you throw it out. Destroy hard copies that contain sensitive data Steps to take when migrating from older medium Encrypt data being migrated between systems Control user access to migrated data Destroy old data storage medium no longer being used Erase hard-drive of old PC with a zero-fill utility

36. A+ Guide to Managing and Maintaining your PC, 6e 36 Perform a Monthly Security Maintenance Routine Change the administrator password Make sure system is being automatically updated Check that AV software is installed and current Visually check the equipment for tampering Check the Event Viewer

37. A+ Guide to Managing and Maintaining your PC, 6e 37 Securing Your Wired or Wireless Network Topics to cover How to use a router to secure a small network How to secure a wireless network Authentication techniques used for larger networks

38. A+ Guide to Managing and Maintaining your PC, 6e 38 Use a Router to Secure a SOHO Network SOHO: a small office or home office Use a router to secure a SOHO network Tasks that routers perform: Limit communication from outside the network Limit communication from within the network Secure a wireless access point Implement a virtual private network (VPN) Keep router firmware current

39. A+ Guide to Managing and Maintaining your PC, 6e 39 Authentication Technologies Controlling network access Encrypt user accounts/passwords at point of entry Decrypt user accounts/passwords before validation Popular authentication protocols: CHAP, Kerberos Two-factor authentication: present two types of id Smart cards Device with id information keyed or read into system Variations: key fob, magnetic strip, and USB smart cards Biometric data: id based on physical characteristics Some biometric devices: iris scanner, fingerprint reader

40. A+ Guide to Managing and Maintaining your PC, 6e 40

41. A+ Guide to Managing and Maintaining your PC, 6e 41

42. A+ Guide to Managing and Maintaining your PC, 6e 42 Dealing with Malicious Software Malicious software (malware or computer infestation) Any unwanted program intending harm to system Transmitted to your computer without your knowledge Examples of malware: viruses and worms Topics to cover How to recognize that a system is infected How to understand how malicious software works How to clean up the mess

43. A+ Guide to Managing and Maintaining your PC, 6e 43 You’ve Got Malware Some signs of malicious messages Pop-up ads plague you when surfing the Web Strange or bizarre error messages appear Less memory than usual is available Strange graphics appear on your computer monitor The system cannot recognize the CD-ROM drive Files constantly become corrupted The OS boots, but cannot launch the Windows desktop Your antivirus software displays one or more messages

44. A+ Guide to Managing and Maintaining your PC, 6e 44 Here's the Nasty List Virus Program that replicates by attaching to other programs Infected program must execute for virus to run Example: boot sector program Protection: run AV software in the background Adware: produces all those unwanted pop-up ads Spam is junk e-mail that you do not want Spyware: program installing itself to spy on you Worm: self-replicating program that overloads network

45. A+ Guide to Managing and Maintaining your PC, 6e 45

46. A+ Guide to Managing and Maintaining your PC, 6e 46 Here's the Nasty List (continued) Browser hijacker: alters home page/browser settings Dialer: dials phone number without your knowledge Keylogger: tracks all your keystrokes Logic bomb: dormant code triggered by an event Trojan horse: disguises itself as a legitimate program

47. A+ Guide to Managing and Maintaining your PC, 6e 47 Here's the Nasty List (continued) Types of viruses Boot sector: virus hides in the boot sector program File virus: hides in executable (.exe, .com, or .sys) Multipartite virus: combined boot sector and file virus Macro virus: hides in documents of macro files Script virus: a virus that hides in a script How malware replicates and hides Uses various techniques to load itself into memory Attempts to hide from AV software Example: stealth virus manipulates its storage file

48. A+ Guide to Managing and Maintaining your PC, 6e 48 Step-by-Step Attack Plan Run reputable AV software Examples: Norton Anti-Virus and McAfee VirusScan Run adware or spyware removal software Example: Windows Defender by Microsoft Search out and destroy what’s left Respond to any startup errors Delete malicious files Purge restore points Clean the registry Root out rootkits

49. A+ Guide to Managing and Maintaining your PC, 6e 49

50. A+ Guide to Managing and Maintaining your PC, 6e 50 Summary Protect accounts and applications with passwords File and folders can be configured for selective permissions Standard security tools: AV software, firewalls, Windows Update Encryption technology: Windows 2000/XP NTFS EFS Techniques used by social engineers: phishing, scam e-mails, virus hoaxes

51. A+ Guide to Managing and Maintaining your PC, 6e 51 Summary (continued) Some events to monitor: failed logon access attempts and network activity Use a router to secure a SOHO network Security techniques for larger networks: smart cards, authentication protocols, biometric devices Malware: invasive programs such as viruses and worms If AV software cannot clean or delete malware, use other techniques such as deleting file from directory
