  1. Extending UML

  2. Why to extend UML? • UML can be used to model any entity, not necessarily software products • Some organizational concepts may not be directly supported by UML • Example • The structure of an organization is generally modeled using a class. • A class supports only three compartments – name of the class, attributes and methods • But the organization has several components such as employees, departments and divisions • See the diagrams on the next slide C-S 546

  3. Organization Classname Division 1 Division 2 Attributes Department 1 Department 2 Methods Employee 11 Employee 12 Employee 21 Employee 22 Department 3 Department 4 Supported by UML Employee 31 Employee 32 Employee 41 Employee 42 Preferred by the designer/modeler C-S 546

  4. Why to extend UML? (continued) • An organization may impose certain restrictions or standards to be followed in modeling • Similar to design standards and coding standards • Example • All classes modeled must have the author name, last modified information etc. to be recorded in the model itself C-S 546

  5. Standard extensions of UML • Tagged values • Indicate additional information for each modeling element • May serve dual purposes • Administrative information such as date created, date modified, author of a model etc. can be recorded • Technical information can provide details for programmer C-S 546

  6. Standard extensions of UML (continued) • Constraints • Conditions can be added to any modeling element or relationship to enrich the semantics of the application • Stereotype extension • The most commonly used extension • Lets the designer create a new modeling element by extending one of the predefined modeling element C-S 546

  7. Tagged Values • Used to add specific properties to modeling elements • Represented as { <tag> = <value> } • curly brackets are part of the syntax • Can be added anywhere in the model • Both <tag> and <value> are represented as strings • Both <tag> and <value> are UNINTERPRETED  designer can put any string value for <tag> or <value> C-S 546

  8. Tagged values – example 1 Check inventory Update inventory Database Inventory manager Inventory System { # of managers = 1 } Tagged value C-S 546

  9. Tagged values – example 2 Account { author = Dr. Jones, created on = Dec 11, 2003 } tagged values Account number : Integer Owner id : Integer Balance : Double { initial value = 0 } Deposit (amt : Double) Withdraw (amt : Double) C-S 546

  10. Tagged values – Example 3 Season change / changeColor() Fall {duration = 3 months} Winter {duration = 3 months} Tagged values C-S 546

  11. Stereotypes • Extends a meta class • Allows user to create his/her own modeling element • Example • Extend the <class> definition to introduce additional information in it • Same meta class can be extended several times into different stereotypes • Includes, in the representation, <<stereotype name>> • Can associate a graphical icon with a stereotype, but it is optional C-S 546

  12. <<Organization>> <<class>> Organization Name Class name Division 1 Division 2 Attributes Department 1 Department 2 Methods Employee 11 Employee 12 Employee 21 Employee 22 Department 3 Department 4 Standard or built-in stereotype, called <<class>> Employee 31 Employee 32 Employee 41 Employee 42 User-defined stereotype, called <<Organization>> Note: a graphical icon is attached to the stereotype <<Organization>> C-S 546

  13. Textual Description of the stereotype <<Organization>> • This stereotype has three components • An organizational name • One or more “Division”s • Each “Division” includes one or more “Department”s • A “Department” may optionally have zero or more employees • The graphical icon attached to this stereotype must show all employees of a department inside a box within the department C-S 546

  14. Defining an interface using stereotype <<Interface>> MathFunctions sin (x : Double) : Double cos (x : Double) : Double tan (x : Double) : Double tanInverse (x : Double) : Double … Note : there is no special graphical icon introduced for <<interface>> C-S 546

  15. Object Constraint Language (OCL) • Previously part of UML; now, it is a separate entity • Started with simple syntax; now, it is enhanced into a formal constraint language by itself • A UML model DOES NOT NEED to include OCL expressions (constraints) • However, use of OCL along with UML enriches the semantics of the application being modeled C-S 546

  16. Why OCL? • Constraints are important in a model to • Provide rich semantics • Capture some intrinsic properties of the application being modeled • Example: only one manager account in an ATM system • To correctly refine a model towards implementation • Otherwise, programmers may have too many choices or the model will become vague C-S 546

  17. Why OCL? (continued) • Constraints can be expressed in natural language(s) • Inherent ambiguities in natural languages • Constraints may be misunderstood creating additional complexities to the problem • Longer constraints become confusing or difficult to specify • Not able to justify or derive additional properties from such constraints C-S 546

  18. More about OCL • Developed as a business modeling language within IBM Insurance Division • A pure and formal constraints language with no side effects • i.e., including OCL expressions in a model will not change the model (or the values in the model) at any time • It only enriches the model with additional constraints C-S 546

  19. More about OCL (continued) • OCL is not a programming language • OCL is independent of implementation and hence implementation languages • OCL expressions are conditions that are discrete and discontinuous • Two sets of constraints on the same model may be totally different and may be specify two different properties of the model • OCL is STRONGLY TYPED • Every expression in OCL must be associated with a type; often, these are Boolean expressions C-S 546

  20. Where to use OCL within a UML model? • To specify invariants on classes and types • An invariant is a condition that is true for the lifetime of a class or a type • To specify pre- and post-conditions on operations • Precondition describes a condition that must be true before the operation is invoked • Post-condition describes a condition that must be true after the operation is completed • To specify guards and conditions on the model C-S 546

  21. Specifying an invariant Context Company inv : self.numberOfEmployees <= 50 Asserts that the attribute “numberOfEmployees” in class “Company” must be always less than or equal to 50. Keywords are shown in bold letters C-S 546

  22. Possible alternative syntax for the same invariant Context c : Company inv : c.numberOfEmployees <= 50 Context c : Company inv maxEmployees : c.numberOfEmployees <= 50 Name of the invariant C-S 546

  23. Specifying pre and post-conditions Context classname :: operationName (param1 : Type1 , …, paramN : TypeN) : ReturnType pre : param1 > param2 post : result = param1 if param1 > paramK = paramK if paramK > param1 Keywords are shown in bold letters You can also attach names to pre- and post-conditions C-S 546

  24. Specifying guards and conditions • Can be specified anywhere in the model using one or more modeling elements and on one or more modeling elements • See conditions in Class diagrams, State transitions diagrams and interactive diagrams (sequence and collaboration diagrams) • Context is implicit when specifying a guard or condition C-S 546

  25. Primitive types and operators C-S 546

  26. Exercises • In the ATM example, introduce two types of accounts – one with permission for overdraft and another without the privilege for overdraft. Show the class diagram. Include tagged values. Define invariant for each class and pre and post-conditions for each method using OCL. C-S 546
