  1. Surface Mount PCB Assembly Process & Printed circuit boards

  2. PCB Assembly, In Xenoa Limited PCB we can assemble the PCBs that the client requires with SMT or Through Hole. • For the assembly of PCB We have the tools and equipment necessary to be able to assemble SMD (Surface Mount Assembly Technology)or THT (Through-Hole Technology) components from prototypes to the volume you need. • We have automatic positioning tools (Pick & Place). • We have a reflow oven for SMT. • We have dip welding for THT. • We have a microcontroller programming service. • We have equipment for visual and electronic validation. • We have equipment to perform rework or re-work for the cards that the client requires a change. • The components can be purchased by Xenoa Limited http://xenoa.co.uk/ providing a complete development and logistics solution or they can be supplied by the customer.’

  3. To quote the PCB assembly in a fast and efficient way send your Gerber files as well as the BOM file (In spreadsheet or CSV format) to the mail sales@xenoa.co.uk Once we get the files we will be answering as soon as possible. PCB assembly policies: GUARANTEE / QUALITY XenoaLimitedHTPx in the PCB assembly process will undertake to keep a limited warranty for a period of 30 business days after the delivery of the products, covering the aspects of the failure of the same that is attributed to the process of manufacturing, manufacturing, and packaging at the time of delivery of the product. QA Xenoa LimitedHTPx in the PCB assembly process will perform an inspection during the product integration process. Xenoa Limited is not responsible for errors in the stages corresponding to the client, such as the design, revision of the list of materials, programming, generation of manufacturing files. Xenoa Limited can stop production due to an error generated by the client.

  4. CONFIDENTIALITY XenoaLimitedHTPx in the PCB assembly process undertakes not to distribute or disseminate customer information regarding the product or project to be quoted, such as PCB manufacturing or design files, bill of materials (BOM), as well as in case of be necessary source code, digital files, or any information provided by the client regarding the product. CANCELLATION / VALIDITY This purchase order after the payment will be canceled only with a written statement from the client expressing the agreement of this document as well as the interest to make the cancellation. The client has a term of 7 working days to request modification or cancellation and this will have a cost of sanction of 2% with respect to the quotation plus the expenses that in case of change or update could be generated. In case of not making the payment this quote has a validity of 5 working days after the date of issue. The price may be canceled in the event of a variance of more than 0.5% of the USD against the MXN.

  5. MANUFACTURE / ORIGIN Xenoa LimitedHTPx in the PCB assembly process decides whether the PCB is ordered to manufacture and assemble in China with Xenoa Limited business partners. HeTPro has the ability to make assemblies in its facilities for manufacturing and validation of printed circuit boards, however, depending on the workload HeTPro will make the decision to choose the place of manufacture. In any case, HeTPro is committed to the quality of the service and finished it. If it is required that the manufacturing is done in one of the two parts please mention it since the price could vary. NOTIFICATIONS OR WARNINGS Any notification of modification, update or agreement of any part of the project must be in writing to any email with the domain of Xenoa Limited to be valid, as well as they must be submitted after the corresponding payment of this quote. LINKS OF INTEREST https://en.wikipedia.org/wiki/Printed_circuit_board http://xenoa.co.uk/pcb-assembly/ http://xenoa.co.uk/pcb-manufacture/ http://xenoa.co.uk/procurement/

  6. GALLERY Aruidno compatibe UNO Freeduino Assembled Card

  7. Assembly validation microscope

  8. Voltage source and hot air gun for rework and testing

  9. Welding stations

  10. Oscilloscope for tests.

  11. Microscope for validation of PCBs.

  12. Microscope for validation of PCBs.

  13. Pick and place team for SMD.

  14. Pick and place PCB

  15. Pick and place, CNC motion system.

  16. Interchangeable heads for components of various sizes SMD.

  17. Rolls of components.

  18. Feeders for rolls of components.

  19. Reflow oven for PCB assembly.

  20. Stencil for welding in paste.

  21. Active carbon filters.

  22. Reflow oven with profiles.

  23. PCB in the process of reflux.

  24. Manual configuration of profiles for reflow stage.

  25. Solder pot or crucible for PTH components.

  26. Thermal control for liquid welding.

  27. Tin in crucible.

  28. Tests and validation of PCBs.

  29. Cutting equipment

  30. Welding in paste.

  31. Pick and place team for SMD with 2 heads. We are PCB design and Printed circuit board manufacturersin UK, we provide you cards of our printed circuit board partners, we are located in Letchworth Garden City , Hertfordshire, UK, however, we deliver to any part of the country. We work on the elaboration of printed circuits in addition to the design. About Xenoa Limited: Xenoa Limited are known to rest and assemble the products with apt housing like milling, case machining or bespoke housing to meet the project requirements. They can also pot or conformal coat the PCB products as needed and are cured with the help of house baking ovens. They also provide excellent support for building the products with the interconnecting cables when needed. They also possess an array of crimp tools to cater to several applications. Contact Information Xenoa Limited Address:- Unit 7 Arden Press Way, Letchworth Garden City , Hertfordshire SG6 1HL Ph.:- 7815980028 Email:- sales@xenoa.co.uk Website:- http://xenoa.co.uk
